Fig. 6

Renal clearance and PCT endocytosis are abrogated in prk_CI/ζ deficient embryos. Embryos were injected with 40-kDa dextran–FITC at 48 hpf, and imaged at 72, 84, and 96 hpf. Control wild-type embryos displayed renal clearance by diminution of the net fluorescent signal intensity over time, as well as dextran–FITC internalization throughout the PCT (white arrows) during its progressive morphogenesis. Doubleprk_CI/ζ morphants displayed severe fluid accumulation, notably pericardial edema that remained strongly positive for the dextran–FITC conjugate label, and the PCT was not labeled by dextran endocytosis (left panels, lateral views; right panels, dorsal views, with exception of bottom right which shows a lateral/dorsal angled view).

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	TU + MO1-prkci + MO1-prkcz
Knockdown Reagents:	MO1-prkci MO1-prkcz
Observed In:	heart pronephric proximal convoluted tubule endocytosis renal filtration
Stage Range:	Protruding-mouth to Day 4

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 396(2), Gerlach, G.F., Wingert, R.A., Zebrafish pronephros tubulogenesis and epithelial identity maintenance are reliant on the polarity proteins Prkc iota and zeta, 183-200, Copyright (2014) with permission from Elsevier. Full text @ Dev. Biol.
