ZFIN ID: ZDB-FIG-090501-25
Peterkin et al., 2009 - Common genetic control of haemangioblast and cardiac development in zebrafish. Development (Cambridge, England)   136(9):1465-1474 Full text @ Development
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Knockdown Reagents:
Anatomical Terms:
Stage Range: 1-4 somites to Prim-5
PHENOTYPE:
Fish:
Knockdown Reagents:
Observed In:
Stage Range: 10-13 somites to Prim-5

Fig. 1 gata4, gata5 and gata6 are essential for anterior haemangioblast specification. (A) gata4, gata5 and gata6 are expressed in overlapping yet distinct domains throughout the anterior lateral plate mesoderm (ALM). (B) Expression of l-plastin, mpx and ikaros, genes associated with myelopoiesis, was absent in gata5+gata6 morphants at 24 hpf. (C) Analysis of earlier regulatory myeloid gene expression on knock down of gata5 and gata6 shows ablation of cmyb, ikaros and pu1 at 10 somites (red arrowheads). (B,C) The number of embryos exhibiting this phenotype shown at the bottom right-hand corner of each panel. (D) Expression of haemangioblast-associated genes close to the onset of their expression was downregulated in gata5+gata6 morphants (marked by red arrowheads where necessary). uncx4.1 was used as a somite marker to stage the embryos (white brackets). n=40-100 for each gene analysed, the pictures shown depict >95% of the embryos. Views are: (A) flatmounted, anterior to the top; (B) lateral, anterior to left, except for ikaros, which is an anterior view; (C) dorsal, anterior to the top; (D) anterior-dorsal.

Gene Expression Details
Gene Antibody Fish Conditions Stage Qualifier Anatomy Assay
drl WT standard conditions 1-4 somites anterior lateral plate mesoderm ISH
WT + MO1-gata5 + MO1-gata6 standard conditions 1-4 somites anterior lateral plate mesoderm ISH
erg WT control 5-9 somites anterior lateral plate mesoderm ISH
WT + MO1-gata5 + MO1-gata6 standard conditions 5-9 somites anterior lateral plate mesoderm ISH
ets1 WT control 5-9 somites anterior lateral plate mesoderm ISH
WT + MO1-gata5 + MO1-gata6 standard conditions 5-9 somites anterior lateral plate mesoderm ISH
etsrp WT control 1-4 somites anterior lateral plate mesoderm ISH
WT + MO1-gata5 + MO1-gata6 standard conditions 1-4 somites anterior lateral plate mesoderm ISH
fli1 WT control 1-4 somites anterior lateral plate mesoderm ISH
WT + MO1-gata5 + MO1-gata6 standard conditions 1-4 somites anterior lateral plate mesoderm ISH
gata2a WT control 1-4 somites anterior lateral plate mesoderm ISH
WT + MO1-gata5 + MO1-gata6 standard conditions 1-4 somites anterior lateral plate mesoderm ISH
hhex WT control 10-13 somites anterior lateral plate mesoderm ISH
WT + MO1-gata5 + MO1-gata6 standard conditions 10-13 somites anterior lateral plate mesoderm ISH
ikzf1 WT control 10-13 somites common myeloid progenitor ISH
Prim-5 head ISH
WT + MO1-gata5 + MO1-gata6 standard conditions 10-13 somites Not Detected common myeloid progenitor ISH
Prim-5 Not Detected head ISH
lcp1 WT control Prim-5 monocyte ISH
WT + MO1-gata5 + MO1-gata6 standard conditions Prim-5 Not Detected monocyte ISH
lmo2 WT control 1-4 somites anterior lateral plate mesoderm ISH
WT + MO1-gata5 + MO1-gata6 standard conditions 1-4 somites anterior lateral plate mesoderm ISH
mpx WT control Prim-5 granulocyte ISH
WT + MO1-gata5 + MO1-gata6 standard conditions Prim-5 Not Detected granulocyte ISH
myb WT control 10-13 somites common myeloid progenitor ISH
WT + MO1-gata5 + MO1-gata6 standard conditions 10-13 somites Not Detected common myeloid progenitor ISH
spi1b WT control 10-13 somites Not Detected common myeloid progenitor ISH
WT + MO1-gata5 + MO1-gata6 standard conditions 10-13 somites common myeloid progenitor ISH
tal1 WT control 1-4 somites anterior lateral plate mesoderm ISH
WT + MO1-gata5 + MO1-gata6 standard conditions 1-4 somites anterior lateral plate mesoderm ISH
uncx4.1 WT control 1-4 somites somite ISH
WT + MO1-gata5 + MO1-gata6 standard conditions 1-4 somites somite ISH
Antibody Labeling Details No data available
Phenotype Details
Fish Conditions Stage Phenotype
WT + MO1-gata5 + MO1-gata6 standard conditions 10-13 somites myeloid cell differentiation disrupted, abnormal
Prim-5 myeloid cell differentiation disrupted, abnormal
