ZFIN ID: ZDB-FIG-090501-30
Peterkin et al., 2009 - Common genetic control of haemangioblast and cardiac development in zebrafish. Development (Cambridge, England)   136(9):1465-1474 Full text @ Development
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Knockdown Reagents:
Anatomical Terms:
Stage Range: 5-9 somites to Prim-5
PHENOTYPE:
Fish:
Knockdown Reagents:
Observed In:
Stage: Prim-5

Fig. 6 Fate of ALM cells in gata5 and gata6 morphants. (A) Fin buds are lost in gata5 and gata6 morphants, as seen by the loss of blimp1 and shh expression (red arrows). Pharyngeal endoderm is slightly reduced in morphants (blimp1, black arrows) compared with wild type. (B) Pronephric mesoderm (wt1 expression) remains unchanged in gata5 and gata6 morphants at 5 somites.

Gene Expression Details
Gene Antibody Fish Conditions Stage Qualifier Anatomy Assay
prdm1a WT control Prim-5 fin bud ISH
Prim-5 pharyngeal endoderm ISH
WT + MO1-gata5 + MO1-gata6 standard conditions Prim-5 Not Detected fin bud ISH
Prim-5 pharyngeal endoderm ISH
wt1a WT control 5-9 somites pronephric mesoderm ISH
WT + MO1-gata5 + MO1-gata6 standard conditions 5-9 somites pronephric mesoderm ISH
Antibody Labeling Details No data available
Phenotype Details
Fish Conditions Stage Phenotype
WT + MO1-gata5 + MO1-gata6 standard conditions Prim-5 fin bud aplastic, abnormal
