Figure 2

Spatial expression of zebrafish GABAA receptor subunits. Whole-mount in situ hybridization of 5 dpf zebrafish larvae using antisense probes for gabra1 (a), gabra2a (b), gabra3 (c), gabra4 (d), gabra5 (e), gabra6a (f), gabra6b (g), gabrb1 (h), gabrb2 (i), gabrb3 (j), gabrb4 (k), gabrg1 (l), gabrg2 (m), gabrg3 (n), gabrd (o), gabrp (p), gabrz (q), gabrr1 (r), gabrr2a (s), gabrr2b (t), gabrr3a (u), and gabrr3b (v). Negative control without probe showing no signals (w). Regions of the olfactory bulb, forebrain, midbrain, hindbrain, and eye are indicated in the image (x). Each labeling image is composed of a whole lateral view (left top), a whole dorsal view (right top), a magnified lateral view of the head region (left bottom), and a magnified dorsal view of the head region (right bottom). The scale bars in the whole and magnified views are 1 mm and 200 μm, respectively. OB: olfactory bulb; FB: forebrain; MB: midbrain; HB: hindbrain.

Expression Data
Genes:
Fish:
Anatomical Terms:
Stage: Day 5
