ZFIN ID: ZDB-FIG-090527-12
Vitorino et al., 2009 - Vsx2 in the zebrafish retina: restricted lineages through derepression. Neural Development   4:14 Full text @ Neural Dev.
ADDITIONAL FIGURES
PHENOTYPE:
Fish:
Knockdown Reagents:
Observed In:
Stage Range: Protruding-mouth to Day 4

Fig. 11 Vsx2 depletion leads to microphthalmia in zebrafish. (A) Lateral and dorsal views of representative 85 hours post-fertilization (hpf) control (Ctrl) and Vsx2 morphant (mo) embryos. Vsx2 morphants are microphthalmic. (B) Graph showing the area of central retina sections of control (wild type (WT)) and Vsx2 morphant (Vsx2MO) at 72 hpf and 96 hpf; 10–20 sections from different eyes were analysed. Vsx2 morphant retinas show a significant (asterisks) reduction in eye area (p < 0.0001). Error bars indicate Standard Error of the Mean.

Gene Expression DetailsNo data available
Antibody Labeling Details No data available
Phenotype Details
Fish Conditions Stage Phenotype
WT + MO2-vsx2 standard conditions Protruding-mouth - Day 4 eye decreased size, abnormal
WT + MO3-vsx2 + MO4-vsx2 standard conditions Protruding-mouth - Day 4 eye decreased size, abnormal
