ZFIN ID: ZDB-FIG-090220-60
Devine et al., 2009 - A dynamic Gli code interprets Hh signals to regulate induction, patterning, and endocrine cell specification in the zebrafish pituitary. Developmental Biology   326(1):143-154 Full text @ Dev. Biol.
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Knockdown Reagents:
Anatomical Terms:
Stage: Prim-25
PHENOTYPE:
Fish:
Knockdown Reagents:
Observed In:
Stage: Prim-25

Fig. 5 Distinct roles for gli genes in pituitary patterning. (A) To block Gli function at later time periods, 17.5 hpf embryos were placed in agarose wells and antisense oligonucleotides were injected into the space below the developing head. (B, C) Late injection of gli3 MOs led to an expansion of ptc1 into the dorsal spinal cord (arrows, spinal cord shown in cross section), consistent with a loss of Gli3 repressor function. This control experiment shows that Gli activity can be reduced by late MO injections. (D) Normal expression of nkx2.2a and prl (inset, ventral view) following control MO injection at 17.5 hpf. (E) Injection of gli1 MOs reduced anterior expression of both nkx2.2a and prl (inset). (F, G) Late injections of gli2a or gli2b antisense MOs or S-oligos led to a posterior expansion of nkx2.2a expression in the placode (arrowheads). (H) Lateral view of the ventral forebrain showing normal prl (blue label) and pomc (red) expression in the placode of control MO injected embryos. (I, J) Late injection of gli2a or gli2b MOs led to ectopic prl expression in the posterior region of the placode (arrowheads), and to a reduction in posterior pomc expression. (D–J) show 40 hpf embryos, anterior to the left. Black lines show the anterior–posterior extent of the placode with the arrowhead pointing to the most posterior extent of gene expression (nkx2.2a or prl). Dotted lines in D, E insets outline the adenohypophysis. Scale bar: B, C; 20 μm, D-J; 35 μm.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
nkx2.2a WT control Prim-25 adenohypophyseal placode ISH
WT + MO1-gli1 standard conditions Prim-25 adenohypophyseal placode ISH
WT + MO1-gli2a standard conditions Prim-25 adenohypophyseal placode ISH
WT + MO3-gli2b standard conditions Prim-25 adenohypophyseal placode ISH
pomca WT control Prim-25 adenohypophyseal placode ISH
WT + MO1-gli2a standard conditions Prim-25 adenohypophyseal placode ISH
WT + MO3-gli2b standard conditions Prim-25 adenohypophyseal placode ISH
prl WT control Prim-25 adenohypophyseal placode ISH
WT + MO1-gli1 standard conditions Prim-25 adenohypophyseal placode ISH
WT + MO1-gli2a standard conditions Prim-25 adenohypophyseal placode ISH
WT + MO3-gli2b standard conditions Prim-25 adenohypophyseal placode ISH
ptch2 WT control Prim-25 spinal cord ISH
WT + MO1-gli3 + MO2-gli3 standard conditions Prim-25 spinal cord ISH
Antibody Labeling Details No data available
Phenotype Details
Fish Conditions Stage Phenotype
WT + MO1-gli1 standard conditions Prim-25 adenohypophysis physical object quality, abnormal
Prim-25 adenohypophysis morphogenesis process quality, abnormal
WT + MO1-gli2a standard conditions Prim-25 adenohypophysis physical object quality, abnormal
Prim-25 adenohypophysis morphogenesis process quality, abnormal
WT + MO1-gli3 + MO2-gli3 standard conditions Prim-25 adenohypophysis morphogenesis process quality, abnormal
Prim-25 spinal cord physical object quality, abnormal
Prim-25 spinal cord dorsal/ventral patterning process quality, abnormal
WT + MO3-gli2b standard conditions Prim-25 adenohypophysis physical object quality, abnormal
Prim-25 adenohypophysis morphogenesis process quality, abnormal
Acknowledgments:
ZFIN wishes to thank the journal Developmental Biology for permission to reproduce figures from this article. Please note that this material may be protected by copyright.

Reprinted from Developmental Biology, 326(1), Devine, C.A., Sbrogna, J.L., Guner, B., Osgood, M., Shen, M.C., and Karlstrom, R.O., A dynamic Gli code interprets Hh signals to regulate induction, patterning, and endocrine cell specification in the zebrafish pituitary, 143-154, Copyright (2009) with permission from Elsevier. Full text @ Dev. Biol.
