FIGURE
Fig. 6
Fig. 6
Formation of pancreatic mesenchyme is independent of isl gene function. Neither the loss of all three isl-genes nor absence of vascularization in cloche mutants results in a loss of fgf10, fgf24 or meis3. Expression patterns of meis3 (A–D), fgf10 (E–H) and fgf24 (I–L) in pancreatic mesenchyme of control embryos (B, F, J), isl1/2a/2b depleted embryos (C, G, K) and cloche mutants (D, H, L). All images are ventral with the exception of A, E, I which are dorsal views. Anterior is to the left. Insets in A, E, I mark the position of the higher resolution images shown on the right side. |
Expression Data
| Genes: | |
|---|---|
| Fish: | |
| Knockdown Reagents: | |
| Anatomical Terms: | |
| Stage: | Long-pec |
Expression Detail
Antibody Labeling
Phenotype Data
Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Developmental Biology, 378(1), Wilfinger, A., Arkhipova, V., and Meyer, D., Cell type and tissue specific function of islet genes in zebrafish pancreas development, 25-37, Copyright (2013) with permission from Elsevier. Full text @ Dev. Biol.
