FIGURE

Fig. S3

ID

ZDB-FIG-070620-27

Publication

Hinits et al., 2007 - Mef2s are required for thick filament formation in nascent muscle fibres

Other Figures

All Figure Page

Back to All Figure Page

Fig. S3

Several morpholino combinations produce the same skeletal muscle phenotype. Confocal stacks of fluorescent immunodetection of slow MyHC (F59, red) and anti-Mef2 (green) antibodies of 24-hpf somites of control and embryos injected with different MO combinations, viewed in lateral flatmount. Phenotype severity in slow muscle fibres correlates with levels of Mef2 in fibre nuclei. Single morpholinos show no detectable defects in slow fibres and wild-type levels of Mef2 in nuclei. Double knockdown with either mef2d/c MO, mef2c+mef2d MOs or mef2c/d MO, shows a similar fibre phenotype. Note the correlation of residual Mef2 (arrows) with better MyHC accumulation. Scale bars: 20 μm.

Expression Data

Gene:	smyhc1
Fish:	WT WT + MO1-mef2ca WT + MO1-mef2ca + MO1-mef2d WT + MO2-mef2ca,mef2d WT + MO3-mef2d,mef2ca
Knockdown Reagents:	MO1-mef2ca MO1-mef2d MO2-mef2ca,mef2d MO3-mef2d,mef2ca
Anatomical Term:	slow muscle cell
Stage:	Prim-5

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
