ZFIN ID: ZDB-FIG-070117-5
Jeong et al., 2007 - Patterning the zebrafish diencephalon by the conserved zinc-finger protein Fezl. Development (Cambridge, England)   134(1):127-136 Full text @ Development
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Anatomical Terms:
Stage Range: 75%-epiboly to 20-25 somites

Fig. 1 fezl expression in the developing forebrain demarcates the prospective telencephalon, hypothalamus and prethalamus. (A-L) Analysis of gene expression. Arrow in F indicates the prospective diencephalon; arrowhead in F indicates the telencephalon; arrowhead in I indicates wnt1 expression; arrow in J and arrowhead in K,L indicate the presumptive ZLI; arrowhead in J indicates the MHB. All are dorsal views except C,D,K,L, which are lateral views. Stages and marker identities are indicated in each panel. di, prospective diencephalon; e, eye region; hy, hypothalamus; hb, hindbrain; mhb, midhindbrain boundary; pd, posterior diencephalon; przli, presumptive ZLI; pt, prethalamus; tel, telencephalon; epi, epiboly; som, somite.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
fezf2 WT standard conditions 75%-epiboly neuroectoderm ISH
Bud neural keel ISH
1-4 somites to 5-9 somites presumptive diencephalon ISH
1-4 somites to 5-9 somites presumptive telencephalon ISH
10-13 somites forebrain ISH
14-19 somites to 20-25 somites diencephalon ISH
14-19 somites to 20-25 somites dorsal telencephalon ISH
foxg1a WT standard conditions 1-4 somites presumptive telencephalon ISH
irx3a WT standard conditions 14-19 somites to 20-25 somites diencephalon ISH
14-19 somites to 20-25 somites hindbrain ISH
14-19 somites to 20-25 somites midbrain ISH
six3b WT standard conditions 1-4 somites to 5-9 somites optic primordium ISH
1-4 somites to 5-9 somites optic vesicle ISH
wnt1 WT standard conditions Bud midbrain hindbrain boundary neural plate ISH
1-4 somites to 5-9 somites midbrain hindbrain boundary neural keel ISH
1-4 somites to 5-9 somites midbrain neural keel ISH
wnt8b WT standard conditions Bud midbrain hindbrain boundary neural plate ISH
10-13 somites midbrain hindbrain boundary neural rod ISH
10-13 somites thalamus ISH
Antibody Labeling Details No data available
Phenotype Details No data available
