ZFIN ID: ZDB-FIG-070117-9
Jeong et al., 2007 - Patterning the zebrafish diencephalon by the conserved zinc-finger protein Fezl. Development (Cambridge, England)   134(1):127-136 Full text @ Development
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Condition:
Anatomical Terms:
Stage: Prim-5

Fig. 5 Overexpression of fezl expands the telencephalon and hypothalamus at the expense of other fore- and mid-brain regions. (A-D) Expansion of telencephalic foxg1 (B) and hypothalamic nk2.1a (D), as compared with wild type (A,C). Arrow in A,B indicates foxg1-expressing cells; arrowhead in C indicates posterior boundary of nk2.1a-expressing cells. (E,F) Expansion of the optic stalk (os), reduction of the eyes and loss of MHB in fezl-overexpressing embryos (F) compared with wild-type (E). Inset in F shows another embryo of the same genotype as that shown in F, with a less-dramatic expansion of optic stalk but missing pax2a-expressing midbrain cells. (G-J) Loss of caudal diencephalic and midbrain irx3a (H) and MHB eng2 (J) expression in fezl-overexpressing embryos. Arrowhead in G,H indicates the mid-hind-brain boundary. All are lateral views of embryonic brain regions labeled with various region-specific markers. Stages and marker identities are specified in each panel. hy, hypothalamus; mhb, mid-hind-brain boundary; tel, telencephalon; os, optic stalk; e, eye region; tc, tectum; hb, hindbrain; pd, posterior diencephalon; tg, tegmentum.

Gene Expression Details
Gene Antibody Fish Conditions Stage Qualifier Anatomy Assay
egr2b WT heat shock Prim-5 rhombomere 3 ISH
Prim-5 rhombomere 5 ISH
zf27Tg; zf28Tg heat shock Prim-5 rhombomere 3 ISH
Prim-5 rhombomere 5 ISH
en2a WT heat shock Prim-5 midbrain hindbrain boundary ISH
zf27Tg; zf28Tg heat shock Prim-5 Not Detected midbrain hindbrain boundary ISH
foxg1a WT heat shock Prim-5 telencephalon ISH
zf27Tg; zf28Tg heat shock Prim-5 telencephalon ISH
irx3a WT heat shock Prim-5 diencephalon ISH
Prim-5 midbrain ISH
zf27Tg; zf28Tg heat shock Prim-5 Not Detected diencephalon ISH
Prim-5 Not Detected midbrain ISH
nkx2.4b WT heat shock Prim-5 hypothalamus ISH
zf27Tg; zf28Tg heat shock Prim-5 hypothalamus ISH
pax2a WT heat shock Prim-5 midbrain hindbrain boundary ISH
Prim-5 optic stalk ISH
zf27Tg; zf28Tg heat shock Prim-5 Not Detected midbrain hindbrain boundary ISH
Prim-5 optic stalk ISH
Antibody Labeling Details No data available
Phenotype Details No data available
