ZFIN ID: ZDB-FIG-200612-25
Weinschutz Mendes et al., 2020 - Expression of dlx genes in the normal and regenerating brain of adult zebrafish. PLoS One   15:e0229549 Full text @ PLoS One
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Anatomical Terms:
Stage: Adult

Fig 1 <italic>dlx1a</italic>, <italic>dlx2a</italic>, <italic>dlx5a</italic> and <italic>dlx6a</italic> are expressed in the adult zebrafish brain.

Schematic representation of sections depicted in the top right panel. In situ hybridization shows dlx expression in cryosections of the adult zebrafish brain. Sagittal section showing dlx5a expression in a 6 mpf fish (A). Transverse sections showing expression throughout areas of the forebrain, midbrain and hindbrain of dlx1a (B-D), dlx2a (B’-D’), dlx5a (B”-D”) and dlx6a (B”’-D”’) in 1 ypf zebrafish (N = 6 for each dlx gene). Hc.: caudal zone of the periventricular hypothalamus; Hd.: dorsal zone of the periventricular hypothalamus; PPa.: anterior part of parvocellular preoptic nucleus; V.: ventral telencephalic area; Vd.: dorsal nucleus of V.; Vp.: parvocellular nucleus of V.; Vv.: ventral nucleus of V. Scale bar (A): 1mm; (B-D”’): 400μm.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
dlx1a WT standard conditions Adult caudal periventricular hypothalamus ISH
Adult dorsal nucleus of ventral telencephalon ISH
Adult dorsal periventricular hypothalamus ISH
Adult forebrain ventral region ISH
Adult postcommissural nucleus of ventral telencephalon ISH
Adult rostral parvocellular preoptic nucleus ISH
Adult ventral nucleus of ventral telencephalon ISH
dlx2a WT standard conditions Adult caudal periventricular hypothalamus ISH
Adult central nucleus of ventral telencephalon ISH
Adult dorsal nucleus of ventral telencephalon ISH
Adult dorsal periventricular hypothalamus ISH
Adult forebrain ventral region ISH
Adult postcommissural nucleus of ventral telencephalon ISH
Adult rostral parvocellular preoptic nucleus ISH
Adult ventral nucleus of ventral telencephalon ISH
dlx5a WT standard conditions Adult caudal periventricular hypothalamus ISH
Adult central nucleus of ventral telencephalon ISH
Adult dorsal nucleus of ventral telencephalon ISH
Adult dorsal periventricular hypothalamus ISH
Adult forebrain ventral region ISH
Adult postcommissural nucleus of ventral telencephalon ISH
Adult rostral parvocellular preoptic nucleus ISH
Adult ventral nucleus of ventral telencephalon ISH
dlx6a WT standard conditions Adult caudal periventricular hypothalamus ISH
Adult dorsal nucleus of ventral telencephalon ISH
Adult dorsal periventricular hypothalamus ISH
Adult forebrain ventral region ISH
Adult postcommissural nucleus of ventral telencephalon ISH
Adult rostral parvocellular preoptic nucleus ISH
Adult ventral nucleus of ventral telencephalon ISH
Antibody Labeling Details No data available
Phenotype Details No data available
