ZFIN ID: ZDB-FIG-090113-104
Chakraborty et al., 2009 - Loss of ribosomal protein L11 affects zebrafish embryonic development through a p53-dependent apoptotic response. PLoS One   4(1):e4152 Full text @ PLoS One
Knockdown Reagent:
Observed In:
Stage: Long-pec

Fig. S4 Phenotype of L11morphants at 2 day post fertilization (dpf). Morphology of L11 morphants (upper panel) shows slightly smaller head and eyes, round grey yolk with thin extension, identical to that observed in L11 mutant (rpl11hi3820btg). Lower panel is the wild-type embryo at day 2 dpf. All images are in lateral views with anterior to the left. Scale bar: 1mm

Gene Expression Details No data available
Antibody Labeling Details No data available
Phenotype Details
Fish Conditions Stage Phenotype
WT + MO1-rpl11 standard conditions Long-pec extension decreased thickness, abnormal
Long-pec eye decreased size, abnormal
Long-pec head decreased size, abnormal
Long-pec yolk circular, abnormal
Long-pec yolk grey, abnormal
ZFIN wishes to thank the journal PLoS One for permission to reproduce figures from this article. Please note that this material may be protected by copyright. Full text @ PLoS One
