Little et al., 2004 - Twisted gastrulation promotes BMP signaling in zebrafish dorsal-ventral axial patterning. Development (Cambridge, England)   131(23):5825-5835 Full text @ Development
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Knockdown Reagent:
Anatomical Terms:
Stage: 5-9 somites

Fig. 3 Interaction between sub-dorsalizing tsg1 knockdown and swirl (bmp2b) heterozygotes. All embryos were injected with 16 ng tsg1 MO. At 24 hpf, an injected wild-type embryo was not dorsalized (A), whereas injected swirl (bmp2b) heterozygous siblings were dorsalized. The extent of dorsalization was categorized as follows: (B) weak, class 1 (arrowhead indicates partial loss of the ventral tail fin); (C) moderate, class 3; and (D) strong, class 4. (E-J) Whole-mount in situ hybridization of myod, pax2a and krox20 in 16 ng tsg1 MO1 injected embryos at the eight-somite stage. Injected wild-type embryos were not affected (E,F), whereas heterozygotes displayed a range of dorsalizations (G,H, moderate; I, strong; J, stronger). (F,H) More posterior views of the same embryos shown in E,G, respectively. (J) The somites extend around the circumference, which is typical of a strong, class 4 dorsalization.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
egr2b WT + MO1-twsg1b standard conditions 5-9 somites presumptive rhombomere 3 ISH
5-9 somites presumptive rhombomere 5 ISH
bmp2btc300a/tc300a + MO1-twsg1b (TU) standard conditions 5-9 somites presumptive rhombomere 3 ISH
5-9 somites presumptive rhombomere 5 ISH
myod1 WT + MO1-twsg1b standard conditions 5-9 somites mesoderm ISH
bmp2btc300a/tc300a + MO1-twsg1b (TU) standard conditions 5-9 somites mesoderm ISH
pax2a WT + MO1-twsg1b standard conditions 5-9 somites midbrain hindbrain boundary neural rod ISH
bmp2btc300a/tc300a + MO1-twsg1b (TU) standard conditions 5-9 somites midbrain hindbrain boundary neural rod ISH
Antibody Labeling Details No data available
Phenotype Details No data available
