ZFIN ID: ZDB-FIG-050120-10
Little et al., 2004 - Twisted gastrulation promotes BMP signaling in zebrafish dorsal-ventral axial patterning. Development (Cambridge, England)   131(23):5825-5835 Full text @ Development
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Anatomical Terms:
Stage: 5-9 somites

Fig. 7 Overexpression of tsg1 RNA causes dorsalization. (A-E) Whole-mount in situ hybridization with pax2.1 (arrowhead), krox20 (brackets) and myod reveals expansion of all three markers in embryos injected with 200 pg tsg1 RNA (C-E) relative to wild type (A,B). (B,D) More posterior views of embryos shown in A and C, respectively. (C,D) Mildly dorsalized and (E) moderately dorsalized embryos. (F-I) At 1 dpf, embryos injected with 100 pg tsg1 RNA show a range of dorsalized phenotypes. (F) Uninjected sibling. (G) Class 1 dorsalization, arrowhead indicates gap in ventral tail fin. (H) Class 2 dorsalization, inset shows duplication in fin fold tissue seen in 50% of class 1 and class 2 embryos. (I) Class 3 phenotype.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
egr2b WT standard conditions 5-9 somites presumptive rhombomere 3 ISH
5-9 somites presumptive rhombomere 5 ISH
myod1 WT standard conditions 5-9 somites mesoderm ISH
pax2a WT standard conditions 5-9 somites midbrain hindbrain boundary neural rod ISH
Antibody Labeling Details No data available
Phenotype Details No data available
