FIGURE

Fig. EV2

ID

ZDB-FIG-241002-54

Publication

Mo et al., 2023 - The mitochondrial ribosomal protein mRpL4 regulates Notch signaling

Other Figures

All Figure Page

Back to All Figure Page

Fig. EV2

Effects of overexpressing Notch signaling components A–D. Representative image of wing imaginal disks (n > 10 wing disks) containing MARCM clones stained for Wg. Notch signaling ligand Dl is overexpressed in wild‐type (A) or mRpL4K14608 mutant (B) cells. Notch signaling ligand Ser is overexpressed in wild‐type (C) or mRpL4K14608 mutant (D) cells. E–H. Representative image of wing imaginal disks (n > 10 wing disks) containing MARCM clones stained for NICD. Full‐length Notch protein (NFL) (E), NEXT (F) and NICD (G) are overexpressed in mRpL4K14608 mutant cells. Blank MARCM clones are generated in the wild‐type wing disks (H).
