Fig. 5

Expression of ALS-linked genes in the trunk of zebrafish during development. The trunks of zebrafish were examined at 4dpf for 18 different ALS-associated genes. (A) prph, (B) matr3l1.2, (C) erbb4a, (D) fig4a, (E) mapta, (F) dctn1b, (G) tia1, (H) vcp, (I) ewsr1a, (J) ewsr1b, (K) hnrnpa1a, (L) hnrnpa1b, (M) chmp2ba, (N) chmp2bb, (O) erbb4b, (P) spg11, (Q) fus, and (R) pfn1. Scale bars represent 200 μm.

Expression Data

Genes:	chmp2ba chmp2bb dctn1b erbb4a erbb4b ewsr1a ewsr1b fig4a fus hnrnpa1a hnrnpa1b mapta matr3l1.2 pfn1 prph spg11 tia1 vcp
Fish:	WT
Anatomical Terms:	gut motor neuron muscle spinal cord trunk trunk dorsal region
Stage Range:	Long-pec to Day 4
