Fig. 6

Elimination ofsox6rescuestnnc1bandsmyhc1expression inprdm1a^nrdmutants. (A-D) Cross sections through the trunk region of embryos that were hybridized with the smyhc1 probe at 30 hours postfertilization (hpf): note that migration of the slow-twitch progenitors is disrupted in prdm1a mutants, and the expression of smyhc1 is dramatically downregulated (cf A and C); in the prdm1a;sox6 double mutant, smyhc1 expression is restored in the adaxial cells, though their migration still appears disrupted (cf. C and D). (E-H) Similar cross sections of wild-type and mutant embryos hybridized with the tnnc1b probe. Expression of tnnc1b is completely lost prdm1a mutants (cf E and G); expression is restored throughout the myotomes in the prdm1a;sox6 double mutants, though at lower levels than in the sox6 single mutant (cf. F and H) are slow specific genes, which are expressed in the superficial slow-twitch fibers in wild-type embryos at 30 hpf (A and B).

Expression Data

Genes:	smyhc1 tnnc1b
Fish:	WT prdm1a^m805/m805 sox6^i291/i291 prdm1a^m805/m805; sox6^i291/i291
Anatomical Terms:	fast muscle cell migratory slow muscle precursor cell myotome slow muscle cell
Stage:	Prim-15

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	prdm1a^m805/m805 sox6^i291/i291 prdm1a^m805/m805; sox6^i291/i291
Observed In:	fast muscle cell migratory slow muscle precursor cell myotome slow muscle cell
Stage:	Prim-15

Phenotype Detail
