Fig. 7

Hepatic sox17 and sox32 expression in wnt2bb mutant and Wnt/β-catenin signaling deficient embryos lacking Fgf10a function. (A-F) Hepatic sox17 expression was present in Wnt/β-catenin signaling deficient embryos treated with SU5402 (1 µM) from 30 to 44 hpf (B) as well as in Wnt/β-catenin signaling deficient embryos lacking Fgf10a function (D). Hepatic sox32 expression was also present in these embryos (F). Dorsal views, anterior to the left. (G-J) There was no clear difference in the hepatic sox17 expression domain among wild-type, fgf10a^-/- and wnt2bb^-/- embryos (G-I). However, it expanded into the extrahepatic duct region in most fgf10a^-/-;wnt2bb^-/- (J, five out of seven embryos). Dorsal views, anterior up. Scale bars, 100 µm.

Expression Data

Genes:	sox17 sox32
Fish:	WT fgf10a^tbvbo/tbvbo wnt2bb^s403/s403 fgf10a^tbvbo/tbvbo; wnt2bb^s403/s403 wnt2bb^s403/s403; w32Tg fgf10a^tbvbo/tbvbo; wnt2bb^s403/s403; w32Tg
Conditions:	heat shock chemical treatment: SU5402, heat shock
Anatomical Terms:	hepatic duct liver
Stage:	Long-pec

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	fgf10a^tbvbo/tbvbo wnt2bb^s403/s403 fgf10a^tbvbo/tbvbo; wnt2bb^s403/s403 wnt2bb^s403/s403; w32Tg fgf10a^tbvbo/tbvbo; wnt2bb^s403/s403; w32Tg
Condition:	heat shock
Observed In:	extrahepatic duct gallbladder development hepatic duct development liver liver development
Stage:	Long-pec

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Mechanisms of Development, 128(11-12), Shin, D., Weidinger, G., Moon, R.T., and Stainier, D.Y., Intrinsic and extrinsic modifiers of the regulative capacity of the developing liver, 525-535, Copyright (2012) with permission from Elsevier. Full text @ Mech. Dev.
