Fig. 8

Early development of ectodermal and mesodermal derivatives in sf3b1^b460 mutants. (A,B) Whole-mount in situ hybridization with islet-1 antisense RNA probes shows that the number of Rohon-Beard precursor cells (arrows) is decreased in sf3b1^b460mutants (dorsal view, anterior to top). (C-F) Whole-mount in situ hybridization with islet-2 antisense RNA probe shows deficiency in the development of Rohon-Beard sensory neurons (arrows), whereas the development of primary motor neurons is comparatively less affected in mutant embryos (asterisks). (G,H) Dorsal view of spinal cords labeled with anti-acetylated tubulin (Anti Ac-tub), anterior to left, showing that the Rohon-Beard sensory neuron phenotype persists at later stages in sf3b1^b460 mutants. K-N: Induction of the neural plate border occurs normally in sf3b1^b460 mutants. Whole-mount in situ hybridization with msxB (K,L) and dlx3 (M,N). (I,J;O,P) The derivatives from paraxial mesoderm and chordamesoderm are not affected in sf3b1^b460mutants. (I,J) Lateral view of whole-mount in situ with ntl, anterior to left. (O,P) Dorsal view of double in situ with crestin (red) and myoD (blue), anterior to top.

Expression Data

Genes:	crestin dlx3b isl1a isl2a msx1b tbxta
Fish:	AB sf3b1^b460/b460
Anatomical Terms:	neural crest cell neural plate notochord primary motor neuron Rohon-Beard neuron
Stage Range:	1-4 somites to 26+ somites

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	sf3b1^b460/b460
Observed In:	neural plate morphogenesis notochord primary motor neuron Rohon-Beard neuron somite
Stage Range:	1-4 somites to 26+ somites

Phenotype Detail
