Fig. 4
Csk knock down did not affect cell specification, nor expression of known regulators of CE cell movements. Csk-MO injected embryos were fixed at 6 hpf and in situ hybridization was done with various probes: (A and B) bone morphogenetic protein 2b, bmp; (C and D) chordin, chd; (E and F) goosecoid, gsc; (G and H) no tail, ntl; (I and J) wnt11; (K and L) yes; (M and N) wnt5; (O and P) fyn. Either lateral views (A–D, K, L, O, and P) or animal pole views (E–H, I, J, M, and N) are depicted here. |
Expression Data
| Genes: | |
|---|---|
| Fish: | |
| Knockdown Reagent: | |
| Anatomical Terms: | |
| Stage: | Shield |
Expression Detail
Antibody Labeling
Phenotype Data
Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Mechanisms of Development, 124(2), Jopling, C., and den Hertog, J., Essential role for Csk upstream of Fyn and Yes in zebrafish gastrulation, 129-136, Copyright (2007) with permission from Elsevier. Full text @ Mech. Dev.
