FIGURE

Fig. 3

ID

ZDB-FIG-061206-8

Publication

Lee et al., 2006 - Canonical Wnt signaling through Lef1 is required for hypothalamic neurogenesis

Other Figures

All Figure Page

Back to All Figure Page

Fig. 3

Lef1 is not required for molecular markers of hypothalamus identity or AP patterning. White circles outline posterior hypothalamus. (A,C,E) Uninjected embryos. (B,D,F) Embryos injected with 2 ng of lef1 MO. (A,B) nk2.1a expression in the entire hypothalamus is unaffected in lef1 morphants at 30 hpf. (C,D) rx3 is still expressed in the anterior hypothalamus in lef1 morphants at 30 hpf. (E,F) emx2 is still expressed in the posterior hypothalamus of lef1 morphants at 30 hpf.

Expression Data

Genes:	emx2 nkx2.4b rx3
Fish:	WT WT + MO2-lef1
Knockdown Reagent:	MO2-lef1
Anatomical Term:	hypothalamus
Stage:	Prim-15

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
