ZFIN ID: ZDB-FIG-050214-12
Dooley et al., 2005 - Zebrafish scl functions independently in hematopoietic and endothelial development. Developmental Biology   277(2):522-536 Full text @ Dev. Biol.
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Anatomical Terms:
Stage: 10-13 somites

Fig. 7 Forced expression of scl RNA in wild-type and spadetail mutants. (A, B) Double ISH for flk1 (blue) or gata1 (red) in uninjected (A) or scl RNA injected (B) embryos. (C, D) myoD transcripts normally present in adaxial cells (black arrow) and somites (blue arrow) are not detected in the scl RNA injected embryos. (E–H) The expression of gata1 (E, F) or flk1 (G, H) in uninjected (E, G) or scl RNA injected (F, H) spt-/- embryos. Brackets indicate anterior head mesoderm; arrow indicates flk1 expression in posterior mesoderm; arrowhead indicates tail bud. All embryos are at the 12-somite stage.

Gene Expression Details
Gene Antibody Fish Conditions Stage Qualifier Anatomy Assay
gata1a WT standard conditions 10-13 somites lateral mesoderm ISH
tbx16b104/b104 (AB) standard conditions 10-13 somites Not Detected lateral mesoderm ISH
kdrl WT standard conditions 10-13 somites lateral mesoderm ISH
tbx16b104/b104 (AB) standard conditions 10-13 somites head mesenchyme ISH
10-13 somites lateral mesoderm ISH
10-13 somites tail bud ISH
myod1 WT standard conditions 10-13 somites somite ISH
Antibody Labeling Details No data available
Phenotype Details No data available
