Figure Caption
Fig. 7 Forced expression of scl RNA in wild-type and spadetail mutants. (A, B) Double ISH for flk1 (blue) or gata1 (red) in uninjected (A) or scl RNA injected (B) embryos. (C, D) myoD transcripts normally present in adaxial cells (black arrow) and somites (blue arrow) are not detected in the scl RNA injected embryos. (E–H) The expression of gata1 (E, F) or flk1 (G, H) in uninjected (E, G) or scl RNA injected (F, H) spt-/- embryos. Brackets indicate anterior head mesoderm; arrow indicates flk1 expression in posterior mesoderm; arrowhead indicates tail bud. All embryos are at the 12-somite stage.
Figure Data
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Developmental Biology, 277(2), Dooley, K.A., Davidson, A.J., and Zon, L.I., Zebrafish scl functions independently in hematopoietic and endothelial development, 522-536, Copyright (2005) with permission from Elsevier. Full text @ Dev. Biol.
