General Information
ZFIN ID: ZDB-FIG-160927-14
Robra et al., 2016 - The Intracellular Signaling Molecule Darpp-32 Is a Marker for Principal Neurons in the Cerebellum and Cerebellum-Like Circuits of Zebrafish. Frontiers in Neuroanatomy   10:81 Full text @ Front. Neuroanat.
Anatomical Terms:
Stage: Adult

Fig. 6

Expression of Darpp-32, Pvalb7 and tyrosine hydroxylase (TH) in the layers of the adult optic tectum. Sagittal sections of the adult optic tectum, dorsal to the top. (A-C) Colocalization of Darpp-32 and Pvalb7 immunoreactivity in somata in the SFGS and in dendrites in SM. The principal dendrite cannot always be fully seen because it does not necessary lie within the plane of the optical section shown. The layers of the optic tectum are indicated on the left hand side. Scale bar: 20 µm. However, note that the expression of Darpp-32 and Pvalb7 in the synaptic layers ventral to the SM does not overlap. (D-F) Intense TH positive fibers are visible in the vicinity of Darpp-32 expressing cell bodies. Scale bar: 50 µm. Abbreviations of the tectal layers from dorsal to ventral: SM, stratum marginale; SO, stratum opticum; SFGS, stratum fibrosum et griseum superficiale; SGC, stratum griseum central; SAC, stratum album central; SPV, stratum periventriculare.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
ppp1r1b Ab1-ppp1r1b WT standard conditions Adult optic tectum IHC
Ab1-ppp1r1b Adult stratum fibrosum et griseum superficiale neuronal cell body IHC
Ab1-ppp1r1b Adult stratum marginale dendrite IHC
th WT standard conditions Adult optic tectum IHC
Antibody Labeling Details
Antibody Assay Fish Conditions Stage Anatomy
Ab1-pvalb IHC WT standard conditions Adult optic tectum
IHC Adult stratum fibrosum et griseum superficiale neuronal cell body
IHC Adult stratum marginale dendrite
Phenotype Details No data available
ZFIN wishes to thank the journal Frontiers in Neuroanatomy for permission to reproduce figures from this article. Please note that this material may be protected by copyright. Full text @ Front. Neuroanat.
