Fig. 5

Fgf Signaling Inhibits Wnt/β-Catenin Signaling via Induction of dkk1

(A and B) SU5402 treatment leads to ectopic induction of the Wnt/β-catenin signaling targets lef1 and axin2 in 36 hpf embryos.

(D–F) (D) dkk1 is a Fgf target, as it is highly upregulated in apc^mcr mutant primordia and is absent in (E) Fgf signaling-depleted WT, as well as in (F) Fgf signaling-depleted apc^mcr mutant primordia.

(G and H) Morpholino knockdown of dkk1 causes expansion of lef1 and axin2, similar to loss of Fgf signaling. The scale bar is equal to 40 μM.

Expression Data

Genes:	axin2 dkk1b lef1
Fish:	WT apc^hu745/hu745 WT + MO1-dkk1b
Condition:	chemical treatment: SU5402
Knockdown Reagent:	MO1-dkk1b
Anatomical Term:	posterior lateral line primordium
Stage:	Prim-25

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	apc^hu745/hu745
Observed In:	posterior lateral line primordium
Stage:	Prim-25

Phenotype Detail
