FIGURE

Fig. S5

ID
ZDB-FIG-080502-17
Publication
Sanek et al., 2008 - A novel role for zebrafish zic2a during forebrain development
Other Figures
All Figure Page
Back to All Figure Page
Fig. S5

Zic2a expression is unaffected by loss of hedgehog signaling. (A, B) Double ISH for zic2a and ptc1 expression in smob641/+ incross progeny at tail-bud stage (TB). (B) Homozygous null embryos were identified by lack of ptc1 expression. (C, D) ISH for zic2a expression in smob641/+ incross progeny at Prim-5 stage. Homozygous null embryos were identified morphologically.

Expression Data
Genes:
Fish:
Anatomical Terms:
Stage Range: Bud to Prim-5

Expression Detail
Antibody Labeling
Phenotype Data

Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 317(1), Sanek, N.A., and Grinblat, Y., A novel role for zebrafish zic2a during forebrain development, 325-335, Copyright (2008) with permission from Elsevier. Full text @ Dev. Biol.
