ZFIN ID: ZDB-FIG-050607-10
Thorpe et al., 2005 - Wnt/β-catenin regulation of the Sp1-related transcription factor sp5l promotes tail development in zebrafish. Development (Cambridge, England)   132(8):1763-1772 Full text @ Development
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Knockdown Reagents:
Anatomical Terms:
Stage: Prim-5
PHENOTYPE:
Fish:
Knockdown Reagents:
Observed In:
Stage: Prim-5

Fig. 4 wnt3a and wnt3a/wnt8 morphants lack mesodermal fates at the expense of floor plate in the caudal tail. All embryos were examined at approximately 27-28 hpf. More mildly affected wnt3a/wnt8 morphants that made some tail structures were selected for these analyses. (A-D) Tails of living 28 hpf embryos, anterior to the left. Arrows in B and D indicate premature termination of the notochord in wnt3a and wnt3a/wnt8 morphants, respectively, and the arrowhead in D marks enlarged neural tube lumen. (E-P) Embryos were fixed at 26 hpf and stained with the indicated marker. The caudal tip of the tail is outlined in black dashes for clarity where necessary. (E-H) Embryos stained with ntl to visualize the notochord, arrowheads indicate ntl expression in the tailbud; arrows in F and H indicate the tip of the truncated notochord. (I-L) α-tropomyosin staining to visualize the somites; arrowheads mark the posterior extent of somite formation. (M-P) Embryos stained for F-spondin to visualize the floor plate; arrow in P indicates the expanded floor plate in wnt3a/wnt8 embryos. (Q-T) Pan-neural ngn1 expression in the neural tube is unaffected by wnt3a and wnt8 inhibition.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
neurog1 AB standard conditions Prim-5 neural tube ISH
AB + MO1-wnt3a standard conditions Prim-5 neural tube ISH
AB + MO1-wnt3a + MO1-wnt8a + MO2-wnt8a standard conditions Prim-5 neural tube ISH
AB + MO1-wnt8a + MO2-wnt8a standard conditions Prim-5 neural tube ISH
spon1a AB standard conditions Prim-5 floor plate ISH
AB + MO1-wnt3a standard conditions Prim-5 floor plate ISH
AB + MO1-wnt3a + MO1-wnt8a + MO2-wnt8a standard conditions Prim-5 floor plate ISH
AB + MO1-wnt8a + MO2-wnt8a standard conditions Prim-5 floor plate ISH
tbxta AB standard conditions Prim-5 notochord ISH
Prim-5 tail bud ISH
AB + MO1-wnt3a standard conditions Prim-5 notochord ISH
Prim-5 tail bud ISH
AB + MO1-wnt3a + MO1-wnt8a + MO2-wnt8a standard conditions Prim-5 notochord ISH
Prim-5 tail bud ISH
AB + MO1-wnt8a + MO2-wnt8a standard conditions Prim-5 notochord ISH
Prim-5 tail bud ISH
tpma AB standard conditions Prim-5 somite ISH
AB + MO1-wnt3a standard conditions Prim-5 somite ISH
AB + MO1-wnt3a + MO1-wnt8a + MO2-wnt8a standard conditions Prim-5 somite ISH
AB + MO1-wnt8a + MO2-wnt8a standard conditions Prim-5 somite ISH
Antibody Labeling Details No data available
Phenotype Details
Fish Conditions Stage Phenotype
AB + MO1-wnt3a standard conditions Prim-5 notochord truncated, abnormal
Prim-5 somite decreased amount, abnormal
Prim-5 tail bud morphology, abnormal
AB + MO1-wnt3a + MO1-wnt8a + MO2-wnt8a standard conditions Prim-5 central canal dilated, abnormal
Prim-5 notochord truncated, abnormal
Prim-5 somite decreased amount, abnormal
Prim-5 tail bud bent, abnormal
Prim-5 tail bud morphology, abnormal
AB + MO1-wnt8a + MO2-wnt8a standard conditions Prim-5 tail bud morphology, abnormal
