Fig. 6

Spatial expression pattern of zebrafish glypicans during segmentation and pharyngula stages.

In situ hybridization was carried out to detect glypican mRNA at 20 somite stage: 19 hpf and pharyngula stages: 24-26 hpf. Lateral view of whole mount embryos, anterior to the left. Expression pattern of gpc1a (A, A′), gpc1b (B, B′); subfigure in B is an optical section indicating expression in yolk cells (arrowheads) and branchial arch primordium, gpc2 (C, C′), gpc3 (D, D′), gpc4 (E, E′), gpc5a (F, F′), gpc5b (G, G′), gpc5c (H, H′), gpc6a (I, I′), gpc6b (J, J′). di, diencephalon; te, telencephalon; hb, hindbrain; tg, tegmentum; nc, neural crest; pm, paraxial mesoderm; som, somites; ba, branchial arch; y, yolk; mb, midbrain; ff, fin fold; ov, otic vesicle; fp, floor plate; psom, posterior somites; ep, epiphysis; tri, trigeminal placode; cl, cloaca; pllp, posterior lateral line primordium; cg, cranial ganglion.

Expression Data

Genes:	gpc1a gpc1b gpc2 gpc3 gpc4 gpc5a gpc5b gpc5c gpc6a gpc6b
Fish:	TL
Anatomical Terms:	anal fin central nervous system cloaca cloacal chamber cranial ganglion diencephalon epiphysis floor plate hindbrain midbrain otic vesicle posterior lateral line primordium somite somite posterior region tegmentum telencephalon trigeminal ganglion ventral fin fold whole organism yolk
Stage Range:	20-25 somites to Prim-5
