Fig. 8

Ectopic myocardial gene expression progressively increases within the tal1-deficient endocardium. (A–H) Optical sections from confocal stacks of wild-type (A, C, E, and G) and tal1-deficient (B, D, F, and H) hearts expressing Tg(myl7:H2A-mCherry) (red) and Tg(fli1a:negfp) (green) at 24 hpf (A and B), 36 hpf (C and D), 48 hpf (E and F) and 60 hpf (G and H), arterial pole at the top. These representative hearts demonstrate the progressive increase in the percentage of endocardial cells expressing Tg(myl7:H2A-mCherry) that occurs between 24 and 60 hpf in tal1-deficient embryos (B, D, F, and H). In contrast, the wild-type endocardium never expresses Tg(myl7:H2A-mCherry) (A, C, E, and G). (B′, D′, F′, and H′) Images display only the myocardial marker from the sections shown in (B, D, F, and H). Arrows indicate examples of endocardial cells ectopically expressing Tg(myl7:H2A-mCherry). (I) Bar graph depicts the average percentage of tal1-deficient endocardial cells expressing Tg(myl7:H2A-mCherry) at each stage examined. Error bars indicate standard deviation (n=4–8 embryos per stage).

Expression Data

Genes:	EGFP mCherry
Fish:	sd12Tg; y7Tg (AB) sd12Tg; y7Tg + MO5-tal1 + MO6-tal1 (AB)
Knockdown Reagents:	MO5-tal1 MO6-tal1
Anatomical Terms:	endocardium myocardium
Stage Range:	Prim-5 to Pec-fin

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	sd12Tg; y7Tg + MO5-tal1 + MO6-tal1 (AB)
Knockdown Reagents:	MO5-tal1 MO6-tal1
Observed In:	endocardium cardiac muscle cell differentiation
Stage Range:	Prim-25 to Pec-fin

Phenotype Detail
