ZFIN ID: ZDB-FIG-130128-6
Torregroza et al., 2012 - Regulation of a Vascular Plexus by gata4 Is Mediated in Zebrafish through the Chemokine sdf1a. PLoS One   7(10):e46844 Full text @ PLoS One
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Gene:
Fish:
Knockdown Reagent:
Anatomical Terms:
Stage: Long-pec
PHENOTYPE:
Fish:
Knockdown Reagent:
Observed In:
Stage Range: Long-pec to Day 5

Fig. 6 The gata4 morphants fail to develop neuromasts of the lateral line due to a failure in neuromast deposition.

A–D: Shown are representative control (A) and gata4 morphant (B) embryos (n >50) that were stained at 5 dpf with 4-Di-2-Asp to detect differentiated neuromasts (the arrow in panel A points to a representative neuromast, N). Control (C) or morphant (D) embryos were stained with an anti-acetylated tubulin antibody to detect the neurons that migrate along with the primordium and innervate the neuromasts (arrowhead in C). While neurons fail to branch off in the morphants, the neuron tracks along the route of the primordium normally (arrow points to this neuron track in D). E–F: Shown are representative control (upper panel) and gata4 morphant (lower panel) embryos at 48 hpf (n >50) derived from the transgenic claudinb:gfp reporter line, which labels the primordium and the deposited neuromasts. Specific patches of deposited cells are present at bilateral positions along the lateral line in control embryos (white arrow in E indicates the leading edge of the migrating primordium on the left side of a control embryo). In morphant embryos the primordium always migrates, and often along the normal route of the lateral line. However, in morphant embryos the migration is delayed (the arrow in F indicates the “lagging” leading edge in a representative morphant embryo), and in some morphant embryos the route was abnormal (not shown). Views are lateral, anterior to the left.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
EGFP zf106Tg control Long-pec lateral line primordium IFL
Long-pec neuromast IFL
zf106Tg + MO1-gata4 standard conditions Long-pec lateral line primordium IFL
Long-pec neuromast IFL
Antibody Labeling Details No data available
Phenotype Details
Fish Conditions Stage Phenotype
WT + MO1-gata4 standard conditions Day 5 neuromast decreased amount, abnormal
Day 5 posterior lateral line lacks parts or has fewer parts of type neuromast, abnormal
Day 5 posterior lateral line neuron decreased branchiness, abnormal
Day 5 posterior lateral line neuron projection mislocalised, abnormal
Day 5 trunk lacks parts or has fewer parts of type neuromast, abnormal
zf106Tg + MO1-gata4 standard conditions Long-pec neuromast deposition decreased process quality, abnormal
Long-pec neuromast deposition disrupted, abnormal
Long-pec neuromast primordium migration delayed, abnormal
Long-pec neuromast primordium migration process quality, abnormal
