FIGURE

Fig. S6

ID

ZDB-FIG-120405-27

Publication

Jao et al., 2012 - A zebrafish model of lethal congenital contracture syndrome 1 reveals Gle1 function in spinal neural precursor survival and motor axon arborization

Other Figures

All Figure Page

Back to All Figure Page

Fig. S6

TUNEL assays rarely detect motoneuron death in Gle1-deficient embryos. (A-L) Transverse cryosections through the spinal cords of the control (A-D), gle1^-/- mutant (E-H) and gle1 morphant (I-L) embryos with their motoneuron nuclei labeled by mnx1:H2A-TagRFP-T transgene at 49 hpf. Sections were subjected to TUNEL reactions to reveal apoptotic cells. Nuclei were counterstained by TO-PRO-3. Note that motoneurons (H2A-TagRFP-T⁺) are rarely labeled by TUNEL (<1%, examples indicated by arrows) in the gle1^-/- mutant (E-H) and gle1 morphant (I-L) embryos, despite the fact that TUNEL⁺ signals are evident in those sections with deficient Gle1 activity (E-L). Scale bar: 10 μm.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image. Full text @ Development
