FIGURE

Fig. S5

ID

ZDB-FIG-120405-26

Publication

Jao et al., 2012 - A zebrafish model of lethal congenital contracture syndrome 1 reveals Gle1 function in spinal neural precursor survival and motor axon arborization

Other Figures

All Figure Page

Back to All Figure Page

Fig. S5

gle1 morphants have an earlier onset of phenotypes than gle1^-/- mutants. (A-D) Embryos from gle1^hi4161a/+ intercross were injected with a mix of two non-overlapping gle1 translation-blocking morpholinos (gle1 MOs, C,D) or with five-nucleotide-mismatched MOs (5mm gle1 MOs) (control, A,B). At 30 hpf, cell death can be seen in the CNS of the gle1 MO-injected morphants (bright field, C; Acridine Orange stained, D), but not in the embryos injected with the 5mm gle1 MOs (bright field, A; Acridine Orange stained, B). (E,F) Motoneuron development was examined by confocal microscopy in embryos from gle1^hi4161a/+ intercross injected with either the gle1 MOs (F) or the 5mm gle1 MOs (E) as described in A-D. At 25 hpf, the gle1 MO-injected embryo (F) develops fewer motoneurons in the spinal cord than the 5mm gle1 MO-injected embryo (E). However, motor axon outgrowth in the gle1 MO-injected embryo still appears normal as compared with the control (E) at this stage. All images are lateral views of the spinal cord. Motoneurons (E,F) were imaged at somites 12-15 above the yolk extension with dorsal to top, anterior to left. Scale bars: 500 μm in D; 25 μm in F.
