Fig. 9
Endocardial morphogenesis is inhibited in floating head (flh) mutants. (A–D) The number of endocardial fn1 (A,B) and kdrl (C,D) -expressing precursors is reduced in the notochord deficient flh-/- mutant embryos as compared to their phenotypically normal siblings at the 18-somite stage. (E–H) NFATc1 expression is reduced in flh mutants at 24hpf (E,F) and 32 hpf (G,H) stages. In all panels, ventral view of flat-mounted embryos, anterior is to the top. |
Expression Data
| Genes: | |
|---|---|
| Fish: | |
| Anatomical Terms: | |
| Stage Range: | 10-13 somites to Prim-15 |
Expression Detail
Antibody Labeling
Phenotype Data
| Fish: | |
|---|---|
| Observed In: | |
| Stage: | 14-19 somites |
Phenotype Detail
