Fig. 2
Transcripts predominantly expressed in the INL. Shown are examples of cDNAs expressed in the inner nuclear layer. (A–C) Expression of pou23 between 36 and 60 hpf. (D–G) Expression of soxp between 36 and 60 hpf. (H–K) Expression of ap2β between 36 and 72 hpf. (L) Expression of inlf12 at 72 hpf. (M) Expression of ap2α at 48 hpf. (N) Expression of horizin at 60 hpf. Expression was studied on plastic sections following whole-embryo in situ hybridization. Arrowheads indicate the midline. hpf, hs postfertilization; prcl, photoreceptor cell layer; inl, inner nuclear layer; gcl, ganglion cell layer. |
Expression Data
| Genes: | |
|---|---|
| Fish: | |
| Anatomical Term: | |
| Stage Range: | Prim-25 to Protruding-mouth |
Expression Detail
Antibody Labeling
Phenotype Data
Phenotype Detail
Acknowledgments
This image is the copyrighted work of the attributed author or publisher, and
ZFIN has permission only to display this image to its users.
Additional permissions should be obtained from the applicable author or publisher of the image.
Reprinted from Developmental Biology, 293(2), Pujic, Z., Omori, Y., Tsujikawa, M., Thisse, B., Thisse, C., and Malicki, J., Reverse genetic analysis of neurogenesis in the zebrafish retina, 330-347, Copyright (2006) with permission from Elsevier. Full text @ Dev. Biol.
