Fig. S3

Posterior Hematopoiesis and Pronephric Duct Development Occurs Normally in lost-a-fin Mutants Normal developmental gene expression in the ventral hematopoietic tissues and pronephric duct was observed by in situ hybridization. The expression of scl (A, B), gata1 (C, D), ikaros (E, F), ae2 globin (G, H), and ae3 globin (I, J) at 18?20 hpf and of cadherin 17 (K, L) at 24 hpf in the ICM was unchanged in lost-a-fin mutant embryos; n > 30 progeny were analyzed in each experiment from crosses of known heterozygotes.

Expression Data

Genes:	cdh17 gata1a hbae3 ikzf1 tal1
Fish:	WT acvr1l^gl2/gl2
Anatomical Term:	intermediate cell mass of mesoderm
Stage Range:	14-19 somites to Prim-5
