ZFIN ID: ZDB-FIG-151102-33
Ghaye et al., 2015 - Progenitor potential of nkx6.1-expressing cells throughout zebrafish life and during beta cell regeneration. BMC Biology   13:70 Full text @ BMC Biol.
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Antibody:
Fish:
Anatomical Terms:
Stage Range: 10-13 somites to Day 4

Fig. 6

The pancreatic expression domain of Nkx6.1 includes the Notch-responsive cells. Immunodetection of endogenous Nkx6.1 (red) and Venus (revealed with anti-GFP, green) in Tg(TP1:VenusPest) (ac′) or GFP in Tg(Tp1:eGFP) embryos (de′) at the indicated stages. All views are ventral with the anterior part to the left and represent either z-plane confocal images (bc′) or confocal projection images (a, a′, d, d′, e, e′). Scale bars = 40 µm. EPD extra-pancreatic duct, IPD intra-pancreatic duct

Gene Expression Details
Gene Antibody Fish Conditions Stage Qualifier Anatomy Assay
EGFP um14Tg standard conditions Pec-fin Not Detected extrapancreatic duct IHC
Pec-fin intrapancreatic duct IHC
Day 4 Not Detected extrapancreatic duct IHC
Day 4 gut IHC
Day 4 intrapancreatic duct IHC
Venus s940Tg standard conditions 10-13 somites pancreas primordium IHC
14-19 somites pancreas primordium IHC
Prim-25 pancreatic duct IHC
Antibody Labeling Details
Antibody Assay Fish Conditions Stage Anatomy
Ab2-nkx6 IHC s940Tg standard conditions 10-13 somites pancreas primordium
IHC 14-19 somites pancreas primordium
IHC Prim-25 pancreatic duct
IHC um14Tg standard conditions Pec-fin extrapancreatic duct
IHC Pec-fin intrapancreatic duct
IHC Day 4 extrapancreatic duct
IHC Day 4 intrapancreatic duct
Phenotype Details No data available
