ZFIN ID: ZDB-FIG-100616-92
Insinna et al., 2010 - Analysis of a zebrafish dync1h1 mutant reveals multiple functions for cytoplasmic dynein 1 during retinal photoreceptor development. Neural Development   5:12 Full text @ Neural Dev.
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Gene:
Antibodies:
Fish:
Anatomical Terms:
Stage: Day 4
PHENOTYPE:
Fish:
Observed In:
Stage Range: Day 4 to Day 5

Fig. 1 The cnb mutation disrupts photoreceptor development. (A-D) Side (A, C) and dorsal (B, D) views of 5-dpf wild-type (A, B) and cnb mutant (C, D) embryos. (E-F) Retinal histology of wild-type (E) and cnb (F) retina at 4 dpf. (G, H) Zpr-1 immunoreactivity (brown) to label double cone photoreceptors (PhR) in 4-dpf wild-type (G) and cnb embryos (H). (I, J) ID1 immunoreactivity (brown) to label rod photoreceptors in 4-dpf wild-type (G) and cnb embryos (H). Nuclei in (G, H) are counterstained with methylene blue. (K-N) Confocal microscopy of wild-type (K, M) and cnb (L, N) whole retina (K, L) and individual rod photoreceptor cells (M, N) from Tg(Xlrho:EGFP)fl1 fish. Green, Xlrho:EGFP-positive cells; red, propidium iodide positive nuclei. Scale bars: 1 mm in (A, C); 40 μm in (E-L); 5 μm in (M, N). EGFP, enhanced green fluorescent protein.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
EGFP dync1h1mw20/mw20; fl1Tg standard conditions Day 4 retinal rod cell IFL
fl1Tg standard conditions Day 4 retinal rod cell IFL
Antibody Labeling Details
Antibody Assay Fish Conditions Stage Anatomy
Ab1-rho IHC WT standard conditions Day 4 retinal rod cell
IHC dync1h1mw20/mw20 standard conditions Day 4 retinal rod cell
zpr-1 IHC WT standard conditions Day 4 retinal cone cell
IHC dync1h1mw20/mw20 standard conditions Day 4 retinal cone cell
Phenotype Details
Fish Conditions Stage Phenotype
dync1h1mw20/mw20 standard conditions Day 4 embryonic retina morphogenesis in camera-type eye process quality, abnormal
Day 4 photoreceptor cell morphogenesis process quality, abnormal
Day 4 retinal cone cell malformed, abnormal
Day 4 retinal rod cell malformed, abnormal
Day 5 embryonic retina morphogenesis in camera-type eye process quality, abnormal
Day 5 retina malformed, abnormal
dync1h1mw20/mw20; fl1Tg standard conditions Day 4 embryonic retina morphogenesis in camera-type eye process quality, abnormal
Day 4 photoreceptor cell morphogenesis process quality, abnormal
Day 4 retinal cone cell malformed, abnormal
Day 4 retinal rod cell malformed, abnormal
