Fig. 3

Isl localization in cardiomyocytes of the future atrium. (A-F) Isl is expressed in cardiac cells located at lateral positions in the cardiac disk. Single z-scans of confocal images of Tg(cmlc2:eGFP) embryos at 23 somites immunofluorescently stained with α-eGFP and α-Isl antibodies. C and F show an overlay with eGFP in green and Isl in red. Images in D-F are magnified views of one side of the cardiac disk. Arrows indicate the eGFP^posIsl^pos cells located at lateral positions (future atrium) of the cardiac disk. The white arrowhead indicates Isl-positive cells in the endocardium and the green arrowhead indicates the Isl signal in the trigeminal sensory ganglion. Scale bars: 50 μm.

Expression Data

Gene:	EGFP
Antibodies:	Ab2-isl Ab3-GFP
Fish:	twu26Tg/+
Anatomical Terms:	heart primordium heart primordium nucleus
Stage:	20-25 somites

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail
