ZFIN ID: ZDB-FIG-070413-15
Hsiao et al., 2007 - A Positive Regulatory Loop between foxi3a and foxi3b Is Essential for Specification and Differentiation of Zebrafish Epidermal Ionocytes. PLoS One   2(1):e302 Full text @ PLoS One
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Anatomical Term:
Stage: 1-4 somites

Fig. S3 Screening for possible notch receptor expression in the epidermal ionocyte domain. Embryos aged at the tail bud (tb) to the 3-somite (3-s) stages were evaluated in situ with either (A) notch1a, (B) notch1b, (C) notch2, or (D) notch3 probes. Results show that notch1a was strongly and ubiquitously expressed in the epidermal ionocyte domain. Other notch genes, on the contrary, were expressed in the ventral ectoderm at a low level.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
notch1a AB standard conditions 1-4 somites ectoderm ISH
Bud ectoderm ISH
notch1b AB standard conditions 1-4 somites ectoderm ISH
Bud ectoderm ISH
notch2 AB standard conditions 1-4 somites ectoderm ISH
Bud ectoderm ISH
notch3 AB standard conditions 1-4 somites ectoderm ISH
Bud ectoderm ISH
Antibody Labeling Details No data available
Phenotype Details No data available
Acknowledgments:
ZFIN wishes to thank the journal PLoS One for permission to reproduce figures from this article. Please note that this material may be protected by copyright. Full text @ PLoS One
