ZFIN ID: ZDB-FIG-051228-10
Solnica-Krezel et al., 1996 - Mutations affecting cell fates and cellular rearrangements during gastrulation in zebrafish. Development (Cambridge, England)   123:67-80
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Anatomical Terms:
Stage Range: Bud to Prim-5
PHENOTYPE:
Fish:
Observed In:
Stage Range: Bud to Prim-5

Fig. 9 Changes in expression patterns of cell type and region-specific genes in mutants affected in convergence and extension. (A,C,E,G) Wild type (wt); (B,D,F) trim209 and (H) knym119 mutant embryos. (A,B) Expression of hlx1 and pax2 mRNA at the tail bud stage, view of developing head region. Anterior is towards the left. (C,D) Expression of pax2 at the tail bud stage. Dorsal view. (E,F) Expression of myoD mRNA at the 10 somite stage. Dorsal view, anterior toward the left. (G,H) Expression of eve1 mRNA in tail at 1 dpf. Note ectopic expression in the mutant embryo. Scale bar, 0.1 mm.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
dbx1a WT standard conditions Bud head ISH
vangl2m209/m209 (AB) standard conditions Bud head ISH
eve1 WT standard conditions Prim-5 post-vent region ISH
gpc4m119/m119 (AB) standard conditions Prim-5 post-vent region ISH
myod1 WT standard conditions 10-13 somites somite ISH
vangl2m209/m209 (AB) standard conditions 10-13 somites somite ISH
pax2a WT standard conditions Bud head ISH
vangl2m209/m209 (AB) standard conditions Bud head ISH
Antibody Labeling Details No data available
Phenotype Details
Fish Conditions Stage Phenotype
gpc4m119/m119 (AB) standard conditions Prim-5 post-vent region malformed, abnormal
Prim-5 post-vent region truncated, abnormal
Prim-5 ventral fin fold cell dislocated proctodeum, abnormal
vangl2m209/m209 (AB) standard conditions Bud convergent extension involved in gastrulation process quality, abnormal
Bud presumptive pronephric mesoderm mislocalised laterally, abnormal
10-13 somites convergent extension involved in gastrulation process quality, abnormal
10-13 somites somite condensed, abnormal
10-13 somites somite increased width, abnormal
