Fig. 6

Decrease in the expression of ventroposterior marker eve1, and lateral expansion of a somitic marker myoD in cpt mutant embryos during somitogenesis. (A,C,E) Wild type (wt); (B) cptm169 and (D,F) cptm52 mutant embryos. (A,B) Expression of myoD and eve1, eve1 expression domain in the tail is indicated by an arrow. (C-F) Expression of myoD mRNA. (A-D) Lateral views, anterior towards the left and dorsal towards the top; (E,F) Dorsolateral view of developing tail. s, somites; ac, adaxial cells. Scale bar, 0.1 mm.

Expression Data
Genes:
Fish:
Anatomical Terms:
Stage Range: 10-13 somites to 14-19 somites
