ZFIN Image: Sanek et al., 2008, Fig. S3


Figure Caption

Fig. S3 Forebrain patterning in zic2a morphants. (A, B) foxg1 expression in the telencephalon is not affected in zic2a morphants. (C, D) eomesa expression is normal in the telencephalon, but is reduced in anterior diencephalon (dashed red lines demarcate border between telencephalon and diencephalon). (E, F) lef1 expression is reduced in the PT region of Zic2a depleted embryos. (G, H) rx3 expression is not affected in the anterior hypothalamus, however (I, J) titf1a is weakly expanded anteriorly. (K, L) lhx1a expression is not affected in zic2a morphants at 2 dpf. Embryos are shown in lateral views, anterior to the left. All numbers for these experiments can be found in Supplementary Table 1.

Figure Data

Expression / Labeling details

Phenotype details

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 317(1), Sanek, N.A., and Grinblat, Y., A novel role for zebrafish zic2a during forebrain development, 325-335, Copyright (2008) with permission from Elsevier. Full text @ Dev. Biol.
