Fig. S1

Expression profiling of zebrafish klf genes.

(A) The gene expression patterns of klf family at 24 hpf. At this stage, klfd, klf2a, klf3, klf8, klf6a, and klf17 are expressed in hematopoietic tissues including ICM and CHT. The specific expression is indicated by arrowheads in black. (B) The expression patterns of Klf family in zebrafish at 36 hpf. The black arrowheads indicate expression of klf2a and klf6a in CHT.

Expression Data
Genes: (all 20)
Fish:
Anatomical Terms: (all 10)
Stage Range: Prim-5 to Prim-25
