Fig. 6
gata1 is required to initiate mpx expression in the ICM region, but later represses it. (A–H) pu.1 expression is greatly increased (n=16/16 and 31/31) while mpx expression is greatly reduced (n=66/66 and 26/26) as analyzed by ISH in gata1 MO knockdown embryos at the 20-somite (A–D) and 24-somite (E–H) stages, respectively. (I–P) Both pu.1 and mpx expression are greatly increased in gata1 morphant embryos at 26 hpf and 32 hpf (n=35/35 and 30/33 for pu.1 expression; n=27/31 and 21/24 for mpx expression at 26 hpf and 32 hpf, respectively). Dorsal is up and anterior is to the left in all panels. |
Expression Data
| Genes: | |
|---|---|
| Fish: | |
| Knockdown Reagent: | |
| Anatomical Term: | |
| Stage Range: | 20-25 somites to Prim-15 |
