ZFIN ID: ZDB-FIG-140320-8
Ekker et al., 1992 - Coordinate embryonic expression of three zebrafish engrailed genes. Development (Cambridge, England)   116:1001-1010
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Anatomical Term:
Stage: Prim-15

Fig. 10 Ectodermal cells in the pectoral fins express the eng1 gene. Parasagittal sections through the distal portion of the pectoral fin buds of 32 h embryos were hybridized with probes for the engt (top) , eng2(middle) or eng3 (bottom) genes. The lateral ectoderm in the ventral part of the bud (arrows) hybridized with only the eng1 probe. The red signals in the lower part of Band C are due to the yolk, rather than specific hybridization, as shown in unhybridized control sections. Scale bar, 50 μm.

Gene Expression Details
Gene Antibody Fish Conditions Stage Qualifier Anatomy Assay
en1a AB standard conditions Prim-15 pectoral fin epidermal cell ISH
en2a AB standard conditions Prim-15 Not Detected pectoral fin ISH
en2b AB standard conditions Prim-15 Not Detected pectoral fin ISH
Antibody Labeling Details No data available
Phenotype Details No data available
