ZFIN ID: ZDB-FIG-140320-5
Ekker et al., 1992 - Coordinate embryonic expression of three zebrafish engrailed genes. Development (Cambridge, England)   116:1001-1010
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Anatomical Term:
Stage Range: 14-19 somites to Prim-25

Fig. 7 The muscle pioneers express the eng1 and eng2 genes. Parasagittal sections through the trunk myotomes of 16 h (A,B) and 24 h (C,D) embryos and 36 h whole-mount embryos (E) were hybridized with probes for the eng1 (A,C,E) or eng2 (B,D) genes. The locations of the muscle pioneers are indicated by the arrows. The red signals in the lower part of D and the brown signals in E are due to pigment cells, rather than specific hybridization, as shown in unhybridized control sections. Scale bar, 50 μm in A,B,D and 35 μm in C and E.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
en1a AB standard conditions 14-19 somites muscle pioneer ISH
Prim-5 muscle pioneer ISH
Prim-25 muscle pioneer ISH
en2a AB standard conditions 14-19 somites muscle pioneer ISH
Prim-5 muscle pioneer ISH
Antibody Labeling Details No data available
Phenotype Details No data available
