ZFIN ID: ZDB-FIG-140311-13
McCarroll et al., 2013 - Fgf3 and Fgf10a work in concert to promote maturation of the epibranchial placodes in zebrafish. PLoS One   8(12):e85087 Full text @ PLoS One
ADDITIONAL FIGURES
EXPRESSION / LABELING:
Genes:
Fish:
Anatomical Terms:
Stage Range: 14-19 somites to 20-25 somites

Fig. 1

Fgf3 and Fgf10a are expressed during epibranchial placode formation.

(A-C) In situ hybridization reveals presence of fgf3 transcript in the mesoderm at 14 hpf (A), and then in the endoderm at 18 (B) and 22 hpf (C). (D-F) In situ hybridization reveals presence of fgf10a transcript in the anterior and posterior lateral line (arrows) and the anterior portion of the otic vesicle at 14 (D),18 (E) and 22 hpf (F). Otic vesicle is outlined by a dotted line in (A-F). Abbreviations: ov, otic vesicle; me, mesoderm; en, endoderm; All, anterior lateral line; Pll, posterior lateral line. Scale bar: 50 μm.

Gene Expression Details
Gene Antibody Fish Conditions Stage Anatomy Assay
fgf3 AB standard conditions 14-19 somites head endoderm ISH
14-19 somites head mesoderm ISH
20-25 somites head endoderm ISH
fgf10a AB standard conditions 14-19 somites anterior lateral line placode ISH
14-19 somites otic placode anterior region ISH
14-19 somites posterior lateral line placode ISH
20-25 somites anterior lateral line placode ISH
20-25 somites otic vesicle anterior region ISH
20-25 somites posterior lateral line placode ISH
Antibody Labeling Details No data available
Phenotype Details No data available
