Fig. S4

Blood and endothelium are affected by inhibiting Fgf8a activity. (A?D): in situ analysis at 12 h after 1 h exposure to Su5402 at 6 h. Control siblings were exposed to just the carrier (5% DMSO). Similar results were obtained using the fgf8a morpholino (data not shown). tal1 expression identifies hematopoietic precursors and fli1a expression identifies endothelial precursors in the trunk (A, B) and in the head (C, D). Embryos are shown from a (A,B) posterior view and (C,D) anterior view, dorsal to the top.

Expression Data

Expression Detail

Antibody Labeling

Phenotype Data

Phenotype Detail

Acknowledgments

This image is the copyrighted work of the attributed author or publisher, and ZFIN has permission only to display this image to its users. Additional permissions should be obtained from the applicable author or publisher of the image.

Reprinted from Developmental Biology, 383(1), Warga, R.M., Mueller, R.L., Ho, R.K., and Kane, D.A., Zebrafish Tbx16 regulates intermediate mesoderm cell fate by attenuating Fgf activity, 75-89, Copyright (2013) with permission from Elsevier. Full text @ Dev. Biol.
