Fig. 2

Light-induced transcripts are expressed ubiquitously.

(A) In situ hybridizations of embryos (at 25 h.p.f.) that were exposed to light (left) or maintained in darkness (right) for the probe against wdr76, (B) cry1a, (C) msrb3, (D) ddb2, (E) prxl2, (F) neil1, (G) tef, (H) gstp1, (I) bzrp1, and (J) hsp90α. All light-induced transcripts are expressed ubiquitously at the early stages of zebrafish development. For most transcripts a gradient is observed with the highest level of expression at the anterior. The wdr76, cry1a, msrb3, tef, and neil1 transcripts are present at substantially higher levels in the retina. The hsp90α and tef transcripts show a distinctive presence in the pineal (indicated by arrowhead).

Expression Data

Genes:	cry1a ddb2 prxl2b gstp1.2 hsp90aa1.2 msrb3 neil1 tefa tspo wdr76
Fish:	WT
Conditions:	constant light constant dark
Anatomical Terms:	epiphysis optic cup whole organism whole organism anterior-posterior gradient
Stage:	Prim-5
