Fig. 2

Positional cloning and expression pattern of radar. (A) s327 maps to chromosome 16 between z25845 (2.3 cM) and z26293 (0.7 cM). (B) Sequencing of WT and s327 cDNA reveals a single C-to-A substitution in position 164 of the radar ORF, resulting in a premature stop codon. (C) Predicted translated peptides arising from radar^WT and radar^s327. The mutation is predicted to result in a truncated protein, lacking the mature signaling domain. (D) Whole-mount in situ hybridization shows a restricted pattern of radar expression in WT embryos. radar mRNA is largely absent from the retina of radar^s327 mutants at all stages. In WT, expression is evident in the distal optic vesicle of WT embryos at 10 somites (arrow). At 26 somites, radar is expressed dorsally, opposite of the optic fissure (green bracket). Note ectopic fissures (red bracket) in radar^s327 mutants. (Scale bars: 150 μm for 10 somites, 250 μm for 26 somites, 50 μm for dissected 26 somite eyes.)

Expression Data

Gene:	gdf6a
Fish:	WT gdf6a^s327/s327
Anatomical Terms:	optic cup optic vesicle
Stage Range:	10-13 somites to 26+ somites

Expression Detail

Antibody Labeling

Phenotype Data

Fish:	gdf6a^s327/s327
Observed In:	optic fissure
Stage:	26+ somites

Phenotype Detail
